Унифицированные простые в использовании IP-телефоны Cisco 6941 предлагают высокую точность воспроизведения звука. Созданы для предприятий, офисов, организаций малого и среднего размера. Рентабельные модели предоставляют доступ к расширенному набору возможностей.
Устройства отличаются безопасностью, гарантируют оптимальное качество и экономичность. Включают VoIP-коммуникации, являются продуктивными и надежными в работе. Удобны для пользователей, располагают превосходным пользовательским интерфейсом.
|
Graphical display |
Pixel-based graphical, monochrome anti-glare displays with white backlighting provide scrollable access to calling features and text-based XML applications. (6921, 6941, 6945 and 6961). |
|
Four softkey buttons and scroll toggle bar |
Your calling options are dynamically present; the scroll toggle bar allows easy movement through the displayed information. (6921, 6941, 6945 and 6961) |
|
Network features |
Network features include Cisco Discovery Protocol and IEEE 802.1 p/q tagging and switching. |
|
Ethernet switch |
The phone has a 10/100BASE-T Ethernet connection through two RJ-45 ports, one for the LAN connection and the other for connecting a downstream Ethernet device such as a PC. The Cisco Unified IP Phone 6945 has a gigabit Ethernet connection. |
|
Volume control |
A volume-control toggle provides easy decibel-level adjustments of the handset, monitor speaker, and ringer. |
|
Dual-position foot stand |
The display is easy to view and the buttons and keys are easy to use; you can remove the foot stand for wall mounting, with mounting holes located on the base of the phone. (6911, 6921, 6941, 6945, 6961). The Cisco Unified IP Phone 6901 has a one position footstand. |
|
Multiple ring tones |
The phone offers seven user-adjustable ring tones. (6921, 6941, 6945 and 6961). |
|
American Disabilities Act (ADA) features |
The hearing-aid-compatible (HAC) handset meets the requirements set by the ADA; it also meets ADA HAC requirements for a magnetic coupling to approved hearing aids. The phone dialing pad also complies with ADA standards. |
|
Signaling protocol support |
The phones are supported in Cisco Unified Communications Manager and Cisco Unified Communications Manager Business Edition Versions 7.1.2 and later using Skinny Client Control Protocol (SCCP) and SIP is supported with Cisco Unified Communications Manager and Cisco Unified Communications Manager Business Edition Versions 7.1.5 and later. |
|
Codec support |
G.711a, G.711, G.729a, G.729b, G.729ab and iLBC audio-compression codecs are supported. Additional G.722 is supported by Cisco Unified IP Phone 6945. |
|
Voice quality |
Comfort-noise generation and voice-activity-detection (VAD) programming is provided on a system basis. |
|
Specification |
Description |
|
Firmware upgrades |
You can download firmware changes from Cisco.com |
|
Software upgrades |
Software upgrades are supported with a Trivial File Transfer Protocol (TFTP) server |
|
Dimensions (H x W x D) |
Cisco Unified IP Phone 6941: 164 x 188 x 205 mm (6.4 x 7.4 x 8.1 in.) |
|
Weight |
Cisco Unified IP Phone 6941: Standard: 1039g (37 oz); Slimline: 1102g (39 oz) |
|
Phone casing composition |
Polycarbonate acrylonitrile butadiene styerene (ABS) plastic |
