Проектор Christie Mirage WU7K-M

• Up to 6,300 ANSI lumens
• 2,500-10,000:1 FOFO
• 650:1 ANSI
• Electronically adjustable iris (manual or dynamic)

• 3-chip 0.96" DMD
• Native WUXGA 1920 x 1200
• Frame delay: as little as one frame

• Native dual-link DVI-D
• Analog BNC (optional)
• Frame-doubled 3D - dual-link DVI, VGA (HDMI, analogue BNC & SDI optional)

• RS232 in/out
• RS422 in
• Ethernet (10/100)
• USB device
• GPIO (RS232 9-pin male connector)
• Built-in backlit LCD keypad
• Remote control (with optional wired XLR connection)
• Slot 1-2 standard (populated):  dual-link DVI-D (330MHz) and VGA (165MHz)
• Slots 3-4 are available for option cards

• Full bandwidth analogue BNC
• Dual-link DVI input card (330MHz), \- VGA (165MHz)
• Dual SD/HD-SDI
• Video decoder
• Twin HDMI

• Embedded Christie Twist™ - internal advanced warping and edge-blending
• LiteLOC™
• Electronically adjusted iris (manual or dynamic)
• Dust-sealed, filter-free design
• Reduced power requirements (as compared to competitive products on the market today) – at maximum brightness the unit only draws 870W; standby power consumption (phantom power draw) is less than 20W
• Reduced noise levels
• LCD keypad – active keys are amber to indicate whether function selected will be seen by the audience
• Motorised yellow notch filter
• Built-in portrait display capabilities*

*Christie M Series stacking frame is required in portrait orientation.

• Motorised horizontal and vertical lens offset
• Scheimpflug (tilt) adjustment
• Built-in light shutter
• Tool-free lens insertion system
• All lenses are optional

• Dual Osram PvIP 200W lamps
• Lamp life: 2000 hours @ 200W , 3000 hours @ 150W

• Provides constant brightness tracking and monitors lamp output. It also automatically adjusts the power to ensure constant, uniform brightness across the image – on a multiple-projector screen or multiple-screen display.

• 100V AC to 240V AC @ 50/60 Hz
• Power consumption: 870W maximum
• Thermal dissipation: 2971BTU/hr
• Operating current: 9A @ 100V

• Weight: 55lb (25kg) without lens
• Shipping weight: 87 lb (38 kg)
• Size: 19.7" W x 22.1" L x 10.2" H (500mm W x 561mm L x 259mm H)

• User manual
• IR remote
• Line cord
• Two dual-link DVI-D cards
• 3D sync cable

• Coarse dust filter
• ILS lens adapter kit
• Stacking frame
• Dual HD/SDI input card
• Twin HDMI input card
• Dual-link DVI input card
• Video decoder input card*

*may not include 3D support

• Operating temperature: 40-104°F (5-40°C)
• Humidity (non-condensing): 20-80% non-condensing
