Коммутатор Ruijie XS-S1960-10GT2SFP-P-H

Model

XS-S1960-10GT2SFP-P-H

Ports

10 10/100/1000BASE-T ports, 2 100/1000BASE-X SFP ports (non-combo), Port 1-8 support PoE/PoE+

Fan Slots

Fanless

Management Ports

1 console port

Switching Capacity

24Gbps

Packet Forwarding Rate

18Mpps

Port Buffer

1.5MB

ARP Table

500

MAC Address

Up to 16K

Routing Entries

64

IP Host Entries
(IPv4/IPv6)

500 (IPv4/IPv6)

ACL Entries

Up to 750

ACL

Standard/Extended/Expert ACL, Extended MAC ACL, ACL 80, IPv6 ACL, ACL logging, ACL counter, ACL remark, Global ACL, ACL redirect

QoS

802.1p/DSCP/TOS traffic classification; Multiple queue scheduling mechanisms, such as SP, WRR, DRR, SP+WFQ, SP+WRR, SP+DRR; Input port-based speed limit; Port-based traffic recognition; Each port supports 8 queue priorities

VLAN

4K 802.1q VLANs, Port-based VLAN, MAC-based VLAN, Protocol-based VLAN, Private VLAN, Voice VLAN, QinQ, IP subnet-based VLAN, GVRP

QinQ

Basic QinQ, Flexible QinQ, 1:1 VLAN switching

Link Aggregation

AP, LACP, Flow balance

Port Mirroring

Many-to-one mirroring, One-to-Many mirroring, Flow-based mirroring, Over devices mirroring, VLAN-based mirroring, VLAN-filtering mirroring, AP-port mirroring, RSPAN, ERSPAN

Spanning Tree Protocols

IEEE802.1d STP, IEEE802.1w RSTP, Standard 802.1s MSTP, Port fast, BPDU filter, BPDU guard, TC guard, TC filter, TC protection, LOOP guard, ROOT guard

DHCP

DHCP server, DHCP client, DHCP snooping, DHCP relay, IPv6 DHCP snooping, IPv6 DHCP client, IPv6 DHCP relay

Multiple Spanning Tree Protocol (MSTP) Instances

64

Maximum Aggregation Port (AP)

Up to 128

Multicast

IGMP v1/v2 snooping, IGMP SGVL/IVGL, IGMP filter, IGMP fast leave

EEE Format

Support IEEE 802.3az standard

G.8032

Support

L2 Features

MAC, EEE, ARP, VLAN, QinQ, Link aggregation, Mirroring, STP, RSTP, MSTP, Broadcast storm control, IGMP v1/v2 snooping, IGMP SGVL/IVGL, IGMP filter, IGMP fast leave, DHCP, Jumbo frame, RLDP, LLDP, REUP, G.8032 ERPS, Layer 2 protocol tunnel

Layer 2 Protocols

IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3x, IEEE802.3ad, IEEE802.1p, IEEE802.1x, IEEE802.3ab, IEEE802.1Q (GVRP), IEEE802.1d, IEEE802.1w, IEEE802.1s

Security

Binding of the IP address, MAC address, and port address; Binding of the IPv6, MAC address, and port address; Filter illegal MAC addresses; Port-based and MAC-based 802.1x; MAB; Portal and Portal 2.0 authentication; ARP-check; DAI; Restriction on the rate of ARP packets; Gateway anti-ARP spoofing; Broadcast suppression; Hierarchical management by administrators and password protection; RADIUS and TACACS+; AAA security authentication (IPv4/IPv6) in device login management; SSH and SSH V2.0; BPDU guard; IP source guard; CPP, NFPP; Port protection

Layer 3 Features

IPv4 static routing, IPv6 static routing, RIP, RIPng, ARP proxy, Neighbor Discovery

Layer 3 Protocols (IPv4)

Static routing, RIP, RIPng

IPv4 Features

Ping, Traceroute

IPv6 Features

0-64 any length mask, ICMPv6, Neighbor Discovery, Manually configure local address, Automatically create local address, IPv6 Ping, IPv6 Tracert, IPv6 extender option head

Basic IPv6 Protocols

IPv6 addressing, Neighbor Discovery (ND), IPv6 ACL, ICMPv6, IPv6 Ping, IPv6 Tracert

IPv6 Routing Protocols

Static routing, RIPng

VSU (Virtual Switch Unit)

NA

Reliability

RAS GR for RIP ERPS (G.8032); REUP dual-link fast switching technology; RLDP (Rapid Link Detection Protocol)

Manageability

SNMPv1/v2c/v3, CLI (Telnet/Console), RMON (1, 2, 3, 9), SSH, Syslog/Debug, RSPAN/ERSPAN, NTP/SNTP, FTP, TFTP, Web, SFLOW，support cable detection and port sleep mode

Smart Temperature Control

Fanless

Other Protocols

FTP, TFTP, DNS client, DNS static

Dimensions
(W x D x H) (mm)

340 × 260 × 44

Rack Height

1RU

MTBF

>200K hours

Lightning Protection

6KV

Power Supply

AC input:
Rated voltage range: 100V to 240V AC
Maximum voltage range: 90V to 264V AC
Frequency: 50 to 60Hz
