Серия является полнофункциональной, предоставляет широкий спектр возможностей. Гарантирует защиту инвестиций, уменьшает стоимость владения. Снабжена интуитивно понятным интерфейсом, легко настраивается.
|
Product Model |
RG-S5750C-28SFP4XS-H |
|||||
|
Fixed port |
GE RJ45 port |
8 (Combo) |
||||
|
GE SFP port |
28 |
|||||
|
10GE SFP+ port |
4 |
|||||
|
Flexible card |
Card slot |
2 |
||||
|
Card type |
1-port QSFP+ dedicated stack card |
|||||
|
Management port |
ETH management port |
1 |
||||
|
Console port (RJ45) |
1 |
|||||
|
Console port (Mini USB) |
1 |
|||||
|
USB 2.0 port |
1 |
|||||
|
Performance |
Switching capacity |
598Gbps/5.98Tbps |
||||
|
Forwarding rate |
222Mpps |
|||||
|
MAC table size |
64,000 |
|||||
|
ARP table size |
20,000 |
|||||
|
Jumbo frame |
9216 Bytes |
|||||
|
Packet buffer |
32Mbit |
|||||
|
Power over Ethernet |
Maximum |
n/a |
||||
|
PoE/PoE+ enabled port |
||||||
|
Standard |
||||||
|
Physical |
Dimensions(WxDxH) |
440 X 300 X 44mm |
||||
|
Unit weight |
4.2kg |
|||||
|
Power supply |
Type |
Hot swappable |
||||
|
Redundancy |
1+1 |
|||||
|
AC frequency |
50/60Hz |
|||||
|
Rated AC voltage |
100~240V |
|||||
|
Maximum AC voltage |
90~264V |
|||||
|
Rated HVDC voltage |
240V DC |
|||||
|
Maximum HVDC voltage |
192~288V DC |
|||||
|
Rated DC voltage |
-36V ~ -72V DC |
|||||
|
Maximum power rating |
140W |
|||||
|
Idle power rating |
55W |
|||||
|
Heat dissipation system |
Dissipation mode |
Air-cooled heat dissipation. Intelligent speed adjustment |
||||
|
Number of fan |
3 |
|||||
|
Airflow |
Air flows in from the left and exhausts from the right |
|||||
|
Certifications |
Safety |
EN 60960-1, IEC 60950-1 |
||||
|
EMC |
EN 300 386 |
|||||
|
Emissions |
EN 55022, EN55032 |
|||||
|
Immunity generic |
EN 55024 |
|||||
|
ESD |
EN 61000-4-2 |
|||||
|
Radiated |
EN 61000-4-3 |
|||||
|
EFT/Burst |
EN 61000-4-4 |
|||||
|
Surge |
EN 61000-4-5 |
|||||
|
Conducted |
EN 61000-4-6 |
|||||
|
Power frequency magnetic field |
EN 61000-4-8 |
|||||
|
Voltage dips and interruptions |
EN 61000-4-11 |
|||||
|
Harmonics |
EN 61000-3-2 |
|||||
|
Flicker |
EN 61000-3-3 |
|||||
|
Anti-gas corrosion |
GB-T2423.51-2012(Refer to IEC 60068-2-60) |
|||||
|
Operating temperature |
0 ℃ ~ 50 ℃ |
|||||
|
Storage temperature |
-40 ℃ ~ 70 ℃ |
|||||
|
Operating humidity |
10%~90% RH |
|||||
|
Storage humidity |
5%~95% RH |
|||||
|
Operating altitude |
-500 ~ 5000m |
|||||
|
MTBF(hours) |
506320 |
|||||
