Коммутатор Cisco Catalyst 6500 WS-C6509-E

Number of Total Expansion Slots:

9

Layer Supported:

2

Form Factor:

Rack-mountable

Height:

17.5"

Width:

21.6"

Depth:

18.2"

Weight (Approximate):

60 lb

Additional Information:

• Scalable Performance
• Support large numbers of IEEE 802.3af PoE devices
• Ideal for enterprises and service providers seeking to reduce total cost of ownership (TCO)
• Clock and VTT Modules: Two replaceable clock modules (CLK-7600=) provide clocking signals to the EOBC channel and the switching bus.
• The Cisco Catalyst 6509-E provides maximum uptime with redundancy and rapid (1 to 3 seconds) stateful failover across supervisor engines.
• The Cisco Catalyst 6509-E supports both Cisco Catalyst OS and Cisco IOS Software
• Provides integrated IP Communications throughout all Cisco Catalyst 6500 Series platforms
• Supports up to eight Catalyst 6500 series modules
• WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be installed in slot 5 or slot 6

Backplane Bandwidth:

• 32 GBps shared bus
• 720 GBps switch fabric

Supervisor Engines:

• Supervisor Engine 1 and Supervisor Engine 2 are installed in slot 1 or slot 2
• Supervisor Engine 32 and Supervisor Engine 720 are installed in slot 5 or slot 6

Cisco Catalyst 6500 Series Modules Supported: Supervisor engines

• Fast Ethernet modules (with IEEE 802.3af Power over Ethernet [PoE])
• Gigabit Ethernet modules (with IEEE 802.3af PoE)
• 10 Gigabit Ethernet modules
• Flex WAN modules
• Shared Port Adaptors/SPA Interface Processors
• Multi-Gigabit services modules (content services ,firewall, intrusion detection, IP Security [IPSec], VPN, network analysis, and Secure Sockets Layer [SSL] acceleration)
