Характеристики
Серия
—
WiNG AP-6522
Тип товара
—
Точка доступа
Тип использования
—
Внутренняя
Тип антенны
—
Внутренняя
Кол-во антенн
—
4
Частота
—
2,4 ГГЦ - 5 ГГЦ
Все характеристики
Условия гарантии
Текст гарантии
Цена действительна только для интернет-магазина и может отличаться от цен в розничных магазинах
| PORTABLE AP, US, BATTERY POWERED |
Технические характеристики
| PHYSICAL CHARACTERISTICS | |
| Dimensions: |
AP 6522 (INTERNAL ANTENNA) 7.5W x 9.5L x 1.1H AP 6522 (EXTERNAL ANTENNA) 5.0W x 7.8L x 1.0H |
| Weight: |
AP 6522 (INTERNAL ANTENNA) 0.85 lbs AP 6522 (EXTERNAL ANTENNA) 1.75 lbs |
| Part number: |
AP 6522 (INTERNAL ANTENNA) AP-6522-66030-US & -WR AP 6522 (EXTERNAL ANTENNA) AP-6522-66040-US & -WR |
| Available mounting configurations: |
AP 6522 (INTERNAL ANTENNA) Wall, Ceiling , Open Beam (with KT-135628-01) AP 6522 (EXTERNAL ANTENNA) Wall, Open Beam, Ceiling (with KT-135628-01) |
| LED indicators: | Yes |
| RADIO CHARACTERISTICS | |
| Operating channels: |
Radio 1: 2.4GHz: Chan 1-13 (2412-2472 MHz), Chan 14 (2484 MHz) Japan only Radio 2: 2.4GHz: Chan 1-13 (2412-2472 MHz), Chan 14 (2484 MHz) Japan only 5GHz: All channels from 5200 MHz to 5825 MHz Actual operating frequencies depend on national regulatory limits |
| Maximum available transmit power: | 2.4GHz: 21dBm per chain, 5.0GHz: 20dBm per chain |
| Transmit power Adjustment: | 1dB increment |
| Antenna configuration: | 1x1, 1x2, 2x2 |
| Operating bands: | 2412 to 2472 MHz and 2484 MHz, 5180 to 5825 MHz |
| POWER SPECIFICATIONS | |
| Operating voltage: | 48Vdc (PoE in) / 12Vdc (Aux in) |
| Operating current: | 0.25A (PoE) / 1.0A (Aux) |
| DC Power Consumption: | 12W Max |
| INTERNAL ANTENNA INFORMATION | |
| INTERNAL ANTENNA DESCRIPTION | VALUES |
| Radio 1: 2.4GHz band | 3.9dBi |
| Radio 2: 2.4GHz band | 4.4dBi |
| Radio 2: 5.0GHz band | 7.5dBi |
| WIRELESS DATA COMMUNICATIONS AND NETWORKING | |
| Data rates supported: |
802.11b/g: 1,2,5.5,11,6,9,12,18,24,36,48, and 54Mbps 802.11a: 6,9,12,18,24,36,48, and 54Mbps, 802.11n: MCS 0-15 up to 300Mbps |
| Network standard: | 802.11a, 802.11b, 802.11g, 802.11n |
| Wireless medium: |
Direct Sequence Spread Spectrum (DSSS) and Orthogonal Frequency Division Multiplexing (OFDM), and Spatial Multiplexing (MIMO) |
| VLANs/WLANs supported: | VLANs and WLANs are controller-dependent |
| Uplink: | Auto-sensing 10/100/1000Base-T Ethernet |
| USER ENVIRONMENT | |
| Operating temperature: | 0 to 40°C |
| Storage temperature: | -40 to 85°C |
| Operating humidity: | 5 to 95% RH, non-condensing |
| Operating altitude: | 8,000 ft @ 28°C |
| Storage humidity: | 85% RH, non-condensing |
| Storage altitude: | 30,000 ft @ 12°C |
| Electrostatic discharge: | 15kV air and 8kV contact @ 50% RH |
| MAXIMUM RADIO TRANSMIT POWER: | |
| SINGLE ANTENNA TRANSMIT POWER |
+21 dBm (2400MHZ) +20 dBm (5200MHZ) |
| DUAL ANTENNA COMPOSITE TRANSMIT POWER |
+24 dBm (2400MHZ) +23 dBm (5200MHZ) |
| REGULATORY | |
| Product safety certifications: | UL 60950, cUL, EU EN 60950, TUV and UL 2043 (external antenna) |
| Radio approvals: | FCC (USA), Industry Canada, CE (Europe) and TELEC pending (Japan) |
|
Серия
|
WiNG AP-6522 |
|
Тип товара
|
Точка доступа |
|
Тип использования
|
Внутренняя |
|
Тип антенны
|
Внутренняя |
|
Кол-во антенн
|
4 |
|
Частота
|
2,4 ГГЦ - 5 ГГЦ |
|
Поддержка PoE
|
Да |
