Точка доступа Cisco Small Business 300 WAP351

Standards

IEEE 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)

Cabling type

Category 5e or better

Antennas

Internal antennas optimized for installation on a wall or ceiling

LED indicators

Power, WLAN, LAN

Operating system

Linux

Ports

5 10/100/1000 Ethernet, with support for 802.3af /at PoE, Power Port for AC adapter (not included)

Power Supply

802.3af/at PoE and External 48V/1.25A DC power adapter (not included)

Buttons

Reset button, Power On/Off

Lock slot

Slot for Kensington lock

Physical dimensions (W x D x H)

9.055 x 9.055 x 1.575 in. (230 x 230 x 40 mm)

Weight

1.34 lb or 0.607 kg

VLAN support

Yes

Number of VLANs

1 management VLAN plus 16 VLANs for SSIDs

802.1X supplicant

Yes

SSID-to-VLAN mapping

Yes

Auto channel selection

Yes

Spanning Tree

Yes

Load balancing

Yes

IPv6

Yes

Layer 2

802.1Q-based VLANS, 16 active VLANS plus 1 management VLAN

WPA/WPA2

Yes, including Enterprise authentication

Access control

Yes, management access control list (ACL) plus MAC ACL

Secure management

HTTPS

SSID broadcast

Yes

Rogue-access-point detection

Yes

Multiple mounting options

Mounting bracket included for easy ceiling or wall mounting

Physical security lock

Kensington lock slot

Quality of service (QoS)

Wi-Fi Multimedia and Traffic Specification (WMM TSPEC), Client QoS

Wireless throughput

Up to 300-Mbps data rate (real-world throughput will vary)

Recommended user support

32 active clients/users per radio

Single Point Setup

Yes

Number of access points per cluster

8

Active clients per cluster

240

Web user interface

Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)

Management protocols

Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour

Remote management

Yes

Event logging

Local, remote syslog, email alerts

Network diagnostics

Logging and packet capture

Web firmware upgrade

Firmware upgradable through web browser, imported/exported configuration file

Dynamic Host Configuration Protocol (DHCP)

DHCP client

IPv6 host

Yes

HTTP redirect

Yes

Frequency

Dual concurrent radios (2.4 and 5 GHz)

Radio and modulation type

Dual radio, orthogonal frequency division multiplexing (OFDM)

WLAN

802.11n

2x3 multiple-input multiple-output (MIMO) with 2 spatial streams on 2.4 GHz

2x2 multiple-input multiple-output (MIMO) with 2 spatial streams on 5 GHz

20, and 40 MHz for 802.11n

PHY data rate up to 600 Mbps

Data rates supported

802.11a/b/g:
