Контроллеры Cisco предлагают гибкую и безопасную беспроводную сеть, работают на базе регулярно обновляемой IOS XE. Выделяются высокой надежностью, используются для растущих предприятий. Оснащены исключительной развертываемостью, экономят время и деньги.
Устройства предоставляют улучшенную доступность и масштабируемость, обеспечивают многоуровневую защиту, имеют централизованное администрирование. Эффективно решают критические проблемы, функционируют с нулевым временем простоя.
|
Wireless |
IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11n, 802.11k, 802.11r, 802.11u, 802.11w, 802.11ac |
|
Wired/switching/routing |
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, 1000BASE-T. 1000BASE-SX, 1000-BASE-LH, IEEE 802.1Q VLAN tagging, IEEE 802.1AX Link Aggregation |
|
Data RFCs |
● RFC 768 UDP ● RFC 791 IP ● RFC 2460 IPv6 (pass-through Bridging mode only) ● RFC 792 ICMP ● RFC 793 TCP ● RFC 826 ARP ● RFC 1122 Requirements for Internet Hosts ● RFC 1519 CIDR ● RFC 1542 BOOTP ● RFC 2131 DHCP ● RFC 5415 CAPWAP Protocol Specification ● RFC 4346 TLS Protocol Version 1.1 |
|
Security standards |
● Wi-Fi Protected Access (WPA) ● IEEE 802.11i (WPA2, RSN) ● RFC 1321 MD5 Message-Digest Algorithm ● RFC 1851 ESP Triple DES Transform ● RFC 2104 HMAC: Keyed Hashing for Message Authentication ● RFC 2246 TLS Protocol Version 1.0 ● RFC 2401 Security Architecture for the Internet Protocol ● RFC 2403 HMAC-MD5-96 within ESP and AH ● RFC 2404 HMAC-SHA-1-96 within ESP and AH ● RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV ● RFC 2407 Interpretation for ISAKMP ● RFC 2408 ISAKMP ● RFC 2409 IKE ● RFC 2451 ESP CBC-Mode Cipher Algorithms ● RFC 3280 Internet X.509 PKI Certificate and CRL Profile ● RFC 4347 Datagram Transport Layer Security ● RFC 4346 TLS Protocol Version 1.1 |
|
Encryption |
● Wired Equivalent Privacy (WEP) and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys) ● Advanced Encryption Standard (AES): Cipher Block Chaining (CBC), Counter with CBC-MAC (CCM), Counter with Cipher Block Chaining Message Authentication Code Protocol (CCMP) ● Data Encryption Standard (DES): DES-CBC, 3DES ● Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit ● Datagram Transport Layer Security (DTLS): AES-CBC ● IPsec: DES-CBC, 3DES, AES-CBC |
|
Authentication, authorization, and accounting (AAA) |
● IEEE 802.1X ● RFC 2548 Microsoft Vendor-Specific RADIUS Attributes ● RFC 2716 PPP EAP-TLS ● RFC 2865 RADIUS Authentication ● RFC 2866 RADIUS Accounting ● RFC 2867 RADIUS Tunnel Accounting ● RFC 2869 RADIUS Extensions ● RFC 3576 Dynamic Authorization Extensions to RADIUS ● RFC 5176 Dynamic Authorization Extensions to RADIUS ● RFC 3579 RADIUS Support for EAP ● RFC 3580 IEEE 802.1X RADIUS Guidelines ● RFC 3748 Extensible Authentication Protocol ● Web-based authentication ● TACACS support for management users |
|
Management |
● Simple Network Management Protocol (SNMP) v1, v2c, v3 ● RFC 854 Telnet ● RFC 1155 Management Information for TCP/IP-Based Internets ● RFC 1156 MIB ● RFC 1157 SNMP ● RFC 1213 SNMP MIB II ● RFC 1350 TFTP ● RFC 1643 Ethernet MIB ● RFC 2030 SNTP ● RFC 2616 HTTP ● RFC 2665 Ethernet-Like Interface types MIB ● RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions ● RFC 2819 RMON MIB ● RFC 2863 Interfaces Group MIB ● RFC 3164 Syslog ● RFC 3414 User-Based Security Model (USM) for SNMPv3 ● RFC 3418 MIB for SNMP ● RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs ● Cisco private MIBs |
|
Management interfaces |
● Web-based: HTTP/HTTPS ● Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port ● Cisco Prime Infrastructure |
|
Interfaces and Indicators |
● 2 10 Gigabit Ethernet interfaces ● Small Form-Factor Pluggable (SFP) options (only Cisco SFPs supported): SFP-10G-SR, SFP-10G-LR ● LED indicators: Network Link, Diagnostics ● 1 service port: 10/100/1000 Mbps Ethernet (RJ-45) |
|
Physical dimensions |
● Dimensions (WxDxH): 17.30 x 28.00 x 1.69 in. (440.0 x 711.4 x 43.0 mm) ● Weight: 35.1 lb (15.9 kg) with 2 power supplies |
|
Environmental conditions |
Air temperature: ● Appliance on: 10° to 35°C (50° to 95°F); altitude: 0 to 914.4 m (3000 ft), decrease system temperature by 1.8°F (1.0°C) for every 1000-foot (305-m) increase in altitude● Appliance off: 5° to 45°C (41° to 113°F); maximum altitude: 3048 m (10,000 ft) ● Storage: -40° to 60°C (-40° to 140°F); maximum altitude: 3048 m (10,000 ft) Humidity: ● Appliance on: 20% to 80%; maximum dew point: 70°F (21°C); maximum rate of change: 9°F (5°C)/hr● Appliance off: 8% to 80%; maximum dew point: 80°F (27°C) Electrical input: ● Sine-wave input (47 - 63 Hz) required● Input voltage range (DC): ◦ Minimum: -40 VDC ◦ Maximum: -75 VDC ● Input voltage low range: ◦ Minimum: 100 VAC ◦ Maximum: 127 VAC ● Input voltage high range: ◦ Minimum: 200 VAC ◦ Maximum: 240 VAC ● Input kilovolt-amperes (kVA), approximately: ◦ Minimum: 0.090 kVA ◦ Maximum: 0.700 kVA ● Heat output (maximum) 2302 Btu per hour (675 watts) ● Acoustical noise emissions: ◦ Sound power, idling: 6.1 bels maximum ◦ Sound power, operating: 6.1 bels maximum |
|
Regulatory compliance |
CE Mark Safety: ● UL 60950-1:2003● EN 60950:2000 ● EMI and susceptibility (Class A) ● U.S.: FCC Part 15.107 and 15.109 ● Canada: ICES-003 ● Japan: VCCI ● Europe: EN 55022, EN 55024 |
