Контроллер Cisco 5500 подготовлен для сетей малых и средних компаний, филиалов, учреждений. Обеспечивает централизованное управление, контролирует работоспособность системы, своевременно устраняет неполадки. Является безопасным, гибким, включает несколько режимов развертывания.
Устройство оборудовано расширяемой программно-управляемой архитектурой, которая способствует развитию бизнеса. Серия оптимизирована для производительности 802. 11ac Wave 2, предлагает повышенную пропускную способность, увеличивает время бесперебойной работы.
|
Wireless |
IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11k, 802.11n, 802.11r, 802.11u, 802.11w, 802.11ac. |
|
Wired/Switching/Routing |
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification, 1000BASE-T. 1000BASE-SX, 1000-BASE-LH, IEEE 802.1Q Vtagging, and IEEE 802.1AX Link Aggregation. |
|
Data Request For Comments (RFC) |
● RFC 768 UDP ● RFC 791 IP ● RFC 2460 IPv6 (pass through Bridging mode only) ● RFC 792 ICMP ● RFC 793 TCP ● RFC 826 ARP ● RFC 1122 Requirements for Internet Hosts ● RFC 1519 CIDR ● RFC 1542 BOOTP ● RFC 2131 DHCP ● RFC 5415 CAPWAP Protocol Specification ● RFC 5416 CAPWAP Binding for 802.11 |
|
Security Standards |
● WPA ● IEEE 802.11i (WPA2, RSN) ● RFC 1321 MD5 Message-Digest Algorithm ● RFC 1851 The ESP Triple DES Transform ● RFC 2104 HMAC: Keyed Hashing for Message Authentication ● RFC 2246 TLS Protocol Version 1.0 ● RFC 2401 Security Architecture for the Internet Protocol ● RFC 2403 HMAC-MD5-96 within ESP and AH ● RFC 2404 HMAC-SHA-1-96 within ESP and AH ● RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV ● RFC 2406 IPsec ● RFC 2407 Interpretation for ISAKMP ● RFC 2408 ISAKMP ● RFC 2409 IKE ● RFC 2451 ESP CBC-Mode Cipher Algorithms ● RFC 3280 Internet X.509 PKI Certificate and CRL Profile ● RFC 3602 The AES-CBC Cipher Algorithm and Its Use with IPsec ● RFC 3686 Using AES Counter Mode with IPsec ESP ● RFC 4347 Datagram Transport Layer Security ● RFC 4346 TLS Protocol Version 1.1 |
|
Encryption |
● WEP and TKIP-MIC: RC4 40, 104 and 128 bits (both static and shared keys) ● AES: CBC, CCM, CCMP ● DES: DES-CBC, 3DES ● SSL and TLS: RC4 128-bit and RSA 1024- and 2048-bit ● DTLS: AES-CBC ● IPSec: DES-CBC, 3DES, AES-CBC |
|
Authentication, Authorization, and Accounting (AAA) |
● IEEE 802.1X ● RFC 2548 Microsoft Vendor-Specific RADIUS Attributes ● RFC 2716 PPP EAP-TLS ● RFC 2865 RADIUS Authentication ● RFC 2866 RADIUS Accounting ● RFC 2867 RADIUS Tunnel Accounting ● RFC 2869 RADIUS Extensions ● RFC 3576 Dynamic Authorization Extensions to RADIUS ● RFC 5176 Dynamic Authorization Extensions to RADIUS ● RFC 3579 RADIUS Support for EAP ● RFC 3580 IEEE 802.1X RADIUS Guidelines ● RFC 3748 Extensible Authentication Protocol ● Web-based authentication ● TACACS support for management users |
|
Management |
● SNMP v1, v2c, v3 ● RFC 854 Telnet ● RFC 1155 Management Information for TCP/IP-Based Internets ● RFC 1156 MIB ● RFC 1157 SNMP ● RFC 1213 SNMP MIB II ● RFC 1350 TFTP ● RFC 1643 Ethernet MIB ● RFC 2030 SNTP ● RFC 2616 HTTP ● RFC 2665 Ethernet-Like Interface types MIB ● RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions ● RFC 2819 RMON MIB ● RFC 2863 Interfaces Group MIB ● RFC 3164 Syslog ● RFC 3414 User-Based Security Model (USM) for SNMPv3 ● RFC 3418 MIB for SNMP ● RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs ● Cisco private MIBs |
|
Management Interfaces |
● Web-based: HTTP/HTTPS ● Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port ● Cisco Wireless Control System (WCS) |
|
Interfaces and Indicators |
● Uplink: 8 (5508) 1000BaseT, 1000Base-SX and 1000Base-LH transceiver slots ● Small Form-Factor Pluggable (SFP) options (only Cisco SFPs supported): GLC-T, GLC-SX-MM, GLC-LH-SM ● LED indicators: link ● Service Port: 10/100/1000 Mbps Ethernet (RJ45) ● Service Port: 10/100/1000 Mbps Ethernet (RJ45) For High Availability for future use ● LED indicators: link ● Utility Port: 10/100/1000 Mbps Ethernet (RJ45) ● LED indicators: link ● Expansion Slots: 1 (5508) ● Console Port: RS232 (DB-9 male/RJ-45 connector included), mini-USB ● Other Indicators: Sys, ACT, Power Supply 1, Power Supply 2 |
|
Physical and Environmental |
● Dimensions (WxDxH): 17.30 x 21.20 x 1.75 in. (440 x 539 x 44.5 mm) ● Weight: 20 lbs (9.1 kg) with 2 power supplies ● Temperature: Operating temperature: 32 to 104°F (0 to 40°C); Storage temperature: -13 to 158°F (‑25 to 70°C) ● Humidity: Operating humidity: 10 95%, noncondensing. Storage humidity: up to 95% ● Input power: 100 to 240 VAC; 50/60 Hz; 1.05 A at 110 VAC, 115W Maximum; 0.523 A at 220 VAC, 115W Maximum; Test Conditions: Redundant Power Supplies, 40C, Full Traffic ● Heat Dissipation: 392 Btu/hour at 110/220 VAC Maximum |
|
Regulatory Compliance |
CE Mark Safety: ● UL 60950-1:2003● EN 60950:2000 ● EMI and susceptibility (Class A) ● U.S.: FCC Part 15.107 and 15.109 ● Canada: ICES-003 ● Japan: VCCI ● Europe: EN 55022, EN 55024 |
